Multiple Imputation Analysis with `mianalyze()`

Introduction

Missing data are common in clinical trials, observational studies, registries, and real-world evidence analyses. A standard approach for handling missing values is multiple imputation (MI), where several complete datasets are generated, each containing plausible replacements for missing observations.

After analysing each imputed dataset, the analyst obtains:

a parameter estimate from each imputation;
a corresponding standard error.

The final step is to combine these results into a single inference. This process is commonly known as pooling or MI analysis and is described by Rubin (1987).

The mianalyze() function in kstools package (no public release yet) implements Rubin’s pooling rules and supports the Barnard-Rubin (1999) small-sample degrees-of-freedom adjustment, equivalent to the EDF= option in SAS PROC MIANALYZE. The exported alias ks_mianalyze() provides the same interface.

library(kstools)

Complete function R source code is provided below:

Code

#' Analogue of SAS PROC MIANALYZE (Rubin pooling)
#'
#' Pools point estimates and standard errors across multiple imputations
#' according to Rubin's rules.  Degrees of freedom follow the Barnard-Rubin
#' (1999) small-sample adjustment when complete-data df are supplied via
#' \code{edf} (equivalent to the SAS \code{EDF=} option).
#'
#' @param est Numeric vector of point estimates from each imputation.
#' @param err Numeric vector of corresponding standard errors.
#' @param alpha Significance level for confidence intervals. Default \code{0.05}.
#' @param theta0 Null value for hypothesis test \eqn{H_0: \theta = \theta_0}.
#' @param edf Complete-data degrees of freedom (positive numeric scalar or
#'   \code{Inf}).
#'   Equivalent to the SAS \code{EDF=} option in \code{PROC MIANALYZE}.
#'   When finite, the Barnard-Rubin (1999) adjusted degrees of freedom
#'   \eqn{v_m^*} are used instead of the Rubin (1987) large-sample
#'   \eqn{v_m}.  Default \code{Inf} (no adjustment, Rubin large-sample df).
#' @param v0 Deprecated alias for \code{edf}.  Kept for backward
#'   compatibility; ignored when \code{edf} is also supplied.
#'
#' @return An object of class \code{ks_mianalyze} with components:
#' \describe{
#'   \item{Estimate}{Pooled estimate.}
#'   \item{StdErr}{Pooled standard error.}
#'   \item{m}{Number of imputations.}
#'   \item{Vb}{Between-imputation variance.}
#'   \item{Vw}{Within-imputation variance.}
#'   \item{Vt}{Total variance.}
#'   \item{df}{Degrees of freedom (adjusted when \code{edf} is finite).}
#'   \item{r}{Relative increase in variance due to nonresponse.}
#'   \item{lambda}{Fraction of missing information.}
#'   \item{re}{Relative efficiency.}
#'   \item{lcl, ucl}{Two-sided confidence limits for \code{Estimate}.}
#'   \item{alpha}{Alpha used for CI.}
#'   \item{theta0}{Null value used in hypothesis test.}
#'   \item{edf}{Complete-data degrees of freedom used.}
#'   \item{minim, maxim}{Min/max of input \code{est}.}
#'   \item{t}{Test statistic for \eqn{H_0}.}
#'   \item{pval}{Two-sided p-value.}
#' }
#'
#' @details
#' Let \eqn{Q_i} and \eqn{U_i} be estimate and variance from imputation \eqn{i}.
#' The pooled estimate is \eqn{\bar{Q} = m^{-1}\sum_i Q_i};
#' within variance \eqn{\bar{U} = m^{-1}\sum_i U_i};
#' between variance \eqn{B = (m-1)^{-1}\sum_i (Q_i-\bar{Q})^2};
#' total variance \eqn{T = \bar{U} + (1 + 1/m)B}.
#'
#' Rubin's (1987) large-sample degrees of freedom are
#' \eqn{v_m = (m-1)(1 + \bar{U}/((1+m^{-1})B))^2}.  When the complete-data
#' degrees of freedom \eqn{v_0} are small and the fraction of missing
#' information is modest, \eqn{v_m} can greatly exceed \eqn{v_0}, which is
#' inappropriate.  The Barnard-Rubin (1999) adjustment computes
#' \eqn{v_m^* = (1/v_m + 1/\hat{v}_{obs})^{-1}} where
#' \eqn{\hat{v}_{obs} = (1-\gamma) v_0 (v_0+1)/(v_0+3)} and
#' \eqn{\gamma = (1+m^{-1})B/T}.
#'
#' @references
#' Barnard, J. and Rubin, D. B. (1999). Small-sample degrees of freedom with
#'   multiple imputation. \emph{Biometrika}, 86, 948--955.
#'
#' Rubin, D. B. (1987). \emph{Multiple Imputation for Nonresponse in Surveys}.
#'   Wiley.
#'
#' SAS Institute Inc. (2013). \emph{SAS/STAT 12.3 User's Guide}. Chapter 58,
#'   The MIANALYZE Procedure.
#'
#' @seealso
#' \code{vignette("mianalyze", package = "kstools")} for worked examples and
#' SAS comparisons.
#'
#' @examples
#' est <- c(0.345, 0.303, 0.298, 0.378)
#' err <- c(0.056, 0.101, 0.099, 0.034)
#' out <- mianalyze(est, err)
#' out
#'
#' ## Barnard-Rubin adjusted df (equivalent to SAS EDF=120)
#' mianalyze(est, err, edf = 120)
#' @name ks_mianalyze
#' @importFrom cli cli_abort
#' @importFrom stats pt qt
#' @export
ks_mianalyze <- function(est, err, alpha = 0.05, theta0 = 0, edf = Inf, v0) {
  if (!is.numeric(est) || !is.numeric(err))
    cli::cli_abort("{.arg est} and {.arg err} must be numeric vectors.")
  if (length(est) != length(err))
    cli::cli_abort("{.arg est} and {.arg err} must have the same length.")
  if (length(est) < 1L)
    cli::cli_abort("{.arg est} and {.arg err} must have at least one value.")
  if (anyNA(est) || anyNA(err) || any(!is.finite(est)) || any(!is.finite(err)))
    cli::cli_abort("{.arg est} and {.arg err} must contain only finite, non-missing values.")
  if (any(err < 0))
    cli::cli_abort("{.arg err} must be non-negative.")
  if (length(alpha) != 1L || is.na(alpha) || alpha <= 0 || alpha >= 1)
    cli::cli_abort("{.arg alpha} must be a single value in (0, 1).")
  if (length(theta0) != 1L || is.na(theta0) || !is.finite(theta0))
    cli::cli_abort("{.arg theta0} must be a single finite numeric value.")

  # Resolve edf / v0 (backward compatibility)
  if (!missing(v0)) {
    if (!missing(edf) && !identical(edf, Inf))
      cli::cli_abort("Specify either {.arg edf} or {.arg v0}, not both.")
    edf <- v0
  }
  if (length(edf) != 1L || is.na(edf) || edf <= 0)
    cli::cli_abort("{.arg edf} must be a single positive value or {.code Inf}.")

  # number of imputations
  m <- length(est)
  # Q.bar - average of the estimator
  Q_bar <- mean(est)
  # W.bar - within-imputation variance
  Vw <- mean(err^2)
  # Between imputation variance
  Vb <- if (m > 1L) sum((est - Q_bar)^2) / (m - 1) else 0
  # Total variance
  Vt <- Vw + Vb + Vb/m

  # Rubin's (1987) degrees of freedom
  if (Vb == 0 && Vw == 0) {
    r <- 0
    df <- Inf
  } else {
    # Relative increase in variance
    r <- if (Vw == 0) Inf else (1 + 1 / m) * Vb / Vw
    df <- if (Vb == 0) Inf else (m-1)*(1+(Vw/(Vb+Vb/m)))^2
  }

  # fraction fo missing information
  lambda <- if (is.infinite(r)) {
    1
  } else if (is.infinite(df)) {
    r / (r + 1)
  } else {
    (r + 2 / (df + 3)) / (r + 1)
  }
  # v.obs - for adjusted DF
  gamma <- if (Vt == 0) 0 else (1 + 1 / m) * Vb / Vt

  # Barnard-Rubin (1999) small-sample adjustment (SAS EDF= option)
  if (is.finite(edf)) {
    v_obs <- (1 - gamma) * edf * (edf + 1) / (edf + 3)
    df <- if (is.infinite(df)) v_obs else 1 / (1 / df + 1 / v_obs)
  }
  # Pooled Std Error
  err_pool <- sqrt(Vt)
  crit <- stats::qt(1 - alpha / 2, df = df)
  # Relative efficiency
  re <- 1 / (1 + lambda / m)
  # Range
  minim <- min(est)
  maxim <- max(est)

  delta <- Q_bar - theta0
  t_val <- if (err_pool == 0) {
    if (delta == 0) NA_real_ else sign(delta) * Inf
  } else {
    delta / err_pool
  }

  p <- if (is.na(t_val)) NA_real_ else 2 * stats::pt(abs(t_val), df = df, lower.tail = FALSE)

  res <- list(
    Estimate = Q_bar,
    StdErr = err_pool,
    m = m,
    Vb = Vb,
    Vw = Vw,
    Vt = Vt,
    df = df,
    r = r,
    lambda = lambda,
    re = re,
    lcl = Q_bar - crit * err_pool,
    ucl = Q_bar + crit * err_pool,
    alpha = alpha,
    theta0 = theta0,
    edf = edf,
    minim = minim,
    maxim = maxim,
    t = t_val,
    pval = p
  )

  class(res) <- c("ks_mianalyze", "list")
  res
}


#' @rdname ks_mianalyze
#' @export
mianalyze <- function(est, err, alpha = 0.05, theta0 = 0, edf = Inf, v0) {
  if (!missing(v0) && !missing(edf) && !identical(edf, Inf))
    cli::cli_abort("Specify either {.arg edf} or {.arg v0}, not both.")
  if (!missing(v0) && missing(edf)) {
    ks_mianalyze(est = est, err = err, alpha = alpha, theta0 = theta0, v0 = v0)
  } else {
    ks_mianalyze(est = est, err = err, alpha = alpha, theta0 = theta0, edf = edf)
  }
}


#' @rdname ks_mianalyze
#' @export
summary.ks_mianalyze <- function(object, ...) {
  variance_tbl <- data.frame(
    Between = object$Vb,
    Within  = object$Vw,
    Total   = object$Vt,
    DF      = object$df,
    check.names = FALSE
  )

  diagnostics_tbl <- data.frame(
    `Relative Increase in Variance` = object$r,
    `Fraction Missing Information`  = object$lambda,
    `Relative Efficiency`           = object$re,
    check.names = FALSE
  )

  estimates_tbl <- data.frame(
    Estimate = object$Estimate,
    `Std Error` = object$StdErr,
    LCL = object$lcl,
    UCL = object$ucl,
    DF = object$df,
    check.names = FALSE
  )

  tests_tbl <- data.frame(
    Minimum = object$minim,
    Maximum = object$maxim,
    Theta0  = object$theta0,
    Statistic = object$t,
    PValue = object$pval,
    check.names = FALSE
  )

  structure(
    list(
      variance = variance_tbl,
      diagnostics = diagnostics_tbl,
      estimates = estimates_tbl,
      tests = tests_tbl,
      m = object$m,
      alpha = object$alpha,
      edf = object$edf
    ),
    class = "summary.ks_mianalyze"
  )
}


#' @export
print.ks_mianalyze <- function(x, ...) {
  s <- summary(x)
  adj <- if (is.finite(s$edf)) " (Barnard-Rubin adjusted)" else ""

  cat(sprintf("\n\n***Variance information (%d Imputations)***\n", s$m))
  cat("Between\t\tWithin\t\tTotal\t\tDF", adj, "\n", sep = "")
  cat("-------\t\t------\t\t-----\t\t--\n")
  cat(sprintf("%.6f\t%.6f\t%.6f\t%.1f\n\n",
      s$variance$Between, s$variance$Within, s$variance$Total, s$variance$DF))

  cat("Relative\tFraction\n")
  cat("Increase\tMissing\t\tRelative\n")
  cat("in Variance\tInformation\tEfficiency\n")
  cat("-----------\t-----------\t----------\n")
  cat(sprintf("%.6f\t%.6f\t%.6f\n",
      s$diagnostics$`Relative Increase in Variance`,
      s$diagnostics$`Fraction Missing Information`,
      s$diagnostics$`Relative Efficiency`))

  cat(sprintf("\n***Parameter estimates (%d Imputations)***\n", s$m))
  cat(sprintf("Estimate\tStd Error\t%.2f%% Confidence Limits\tDF\n", 100 * (1 - s$alpha)))
  cat("--------\t---------\t------------------------\t--\n")
  cat(sprintf("%.6f\t%.6f\t%.6f\t%.6f\t%.1f\n",
      s$estimates$Estimate, s$estimates$`Std Error`,
      s$estimates$LCL, s$estimates$UCL, s$estimates$DF))

  cat("\n\t\t\t\t\t\tt for H0\n")
  cat("Minimum\t\tMaximum\t\tTheta0\t\tParameter=Theta0\tPr>|t|\n")
  cat("-------\t\t-------\t\t------\t\t----------------\t------\n")
  cat(sprintf("%.6f\t%.6f\t%.2f\t\t%.4f\t\t\t%.4f\n",
      s$tests$Minimum, s$tests$Maximum, s$tests$Theta0,
      s$tests$Statistic, s$tests$PValue))

  invisible(x)
}


#' @rdname ks_mianalyze
#' @importFrom knitr knit_print kable
#' @exportS3Method knitr::knit_print
knit_print.ks_mianalyze <- function(x, ...) {
  s <- summary(x)

  out <- c(
    sprintf("## Variance Information (%d Imputations)\n", s$m),
    knitr::kable(s$variance, digits = 6),

    "\n\n",

    "## Missing Data Diagnostics\n",
    knitr::kable(s$diagnostics, digits = 6),

    "\n\n",

    sprintf("## Parameter Estimates (%d Imputations)\n", s$m),
    knitr::kable(s$estimates, digits = 6),

    "\n\n",

    "## Hypothesis Test\n",
    knitr::kable(s$tests, digits = 6)
  )

  knitr::asis_output(paste(out, collapse = "\n"))
}

Multiple Imputation Workflow

The typical workflow is:

Create \(m\) imputed datasets.
Perform the same analysis on each dataset.
Extract parameter estimates and standard errors.
Pool the results using Rubin’s rules.

Conceptually:

flowchart TD
    A([Original Dataset])
    B([Multiple Imputation])
    D1[Imputed Dataset 1<br/>Q₁, U₁]
    D2[Imputed Dataset 2<br/>Q₂, U₂]
    D3[Imputed Dataset 3<br/>Q₃, U₃]
    Ddots[...]
    Dm[Imputed Dataset m<br/>Qₘ, Uₘ]
    R{{Rubin's Rules<br/>Pool Estimates and Variances}}
    F([Pooled Estimate<br/>SE, CI, p-value])

    A --> B
    B --> D1
    B --> D2
    B --> D3
    B --> Ddots
    B --> Dm
    D1 --> R
    D2 --> R
    D3 --> R
    Ddots --> R
    Dm --> R
    R --> F

    classDef source fill:#1e40af,stroke:#93c5fd,stroke-width:2px,color:#f8fafc;
    classDef process fill:#c2410c,stroke:#fdba74,stroke-width:2px,color:#f8fafc;
    classDef imputed fill:#166534,stroke:#86efac,stroke-width:2px,color:#f8fafc;
    classDef pooling fill:#6d28d9,stroke:#c4b5fd,stroke-width:2px,color:#f8fafc;
    classDef result fill:#15803d,stroke:#86efac,stroke-width:3px,color:#f8fafc;

    class A source;
    class B process;
    class D1,D2,D3,Dm imputed;
    class R pooling;
    class F result;

    linkStyle default stroke:#94a3b8,stroke-width:1.5px

Rubin’s Rules

Suppose \(Q_i\) is the estimate from imputation \(i\) and \(U_i\) is its variance. Let \(m\) be the number of imputations.

Pooled Estimate

\[\bar{Q} = \frac{1}{m} \sum_{i=1}^{m}Q_i\]

Within-Imputation Variance

\[\bar{U} = \frac{1}{m} \sum_{i=1}^{m}U_i\]

This quantity reflects uncertainty that would exist even if no data were missing.

Between-Imputation Variance

\[B = \frac{1}{m-1}\sum_{i=1}^{m}(Q_i-\bar{Q})^2\]

Large values indicate substantial uncertainty due to missing data.

Total Variance

\[T = \bar{U} + \left(1+\frac{1}{m}\right) B\]

The pooled standard error is \(SE = \sqrt{T}\).

Relative Increase in Variance

\[r = \frac{\left(1+\frac{1}{m}\right) B}{\bar{U}}\]

Values near zero indicate little impact from missing data.

Fraction of Missing Information

For finite Rubin degrees of freedom \(v_m\),

\[\hat\lambda = \frac{r + 2/(v_m + 3)}{r + 1}\]

When \(v_m\) is treated as infinite (large-sample case), this simplifies to \(\hat\lambda = r/(r+1)\). The quantity is often interpreted as the proportion of uncertainty attributable to missingness.

\(\lambda\)	Interpretation
\(< 0.05\)	Negligible missing information
\(0.05\)–\(0.20\)	Mild impact
\(0.20\)–\(0.50\)	Moderate impact
\(> 0.50\)	Severe impact

Relative Efficiency

\[RE = \frac{1}{1 + \lambda/m}\]

Values close to 1 indicate that additional imputations would provide little benefit.

Degrees of Freedom

Rubin (1987)

\[v_m = (m-1)\left(1+\frac{\bar{U}}{\left(1+m^{-1}\right)B}\right)^2\]

When \(m\) is small and missing information is limited, \(v_m\) can become very large.

Problem with Large-Sample Degrees of Freedom

Suppose a model parameter is based on only 40 residual degrees of freedom. Rubin’s formula may yield \(v_m = 500\), which exceeds the information available in the complete-data analysis and can produce confidence intervals that are unrealistically narrow.

Barnard-Rubin Adjustment

Barnard and Rubin (1999) proposed a small-sample correction. Let \(v_0\) be the complete-data degrees of freedom. Define

\[\gamma = \frac{(1 + m^{-1}) B}{T}\]

and

\[\hat{v}_{obs} = (1-\gamma)\, v_0\, \frac{v_0+1}{v_0+3}\]

The adjusted degrees of freedom are

\[v_m^* = \left(\frac{1}{v_m} + \frac{1}{\hat{v}_{obs}}\right)^{-1}\]

This is the method used by SAS PROC MIANALYZE when EDF= is specified, and by mianalyze(edf = ...).

Basic Example

est <- c(0.345, 0.303, 0.298, 0.378)
err <- c(0.056, 0.101, 0.099, 0.034)
out <- mianalyze(est, err)
out

Variance Information (4 Imputations)

Between	Within	Total	DF
0.001426	0.006074	0.007856	58.2727

Missing Data Diagnostics

Relative Increase in Variance	Fraction Missing Information	Relative Efficiency
0.293488	0.252131	0.940705

Parameter Estimates (4 Imputations)

Estimate	Std Error	LCL	UCL	DF
0.331	0.088634	0.153597	0.508403	58.2727

Hypothesis Test

Minimum	Maximum	Theta0	Statistic	PValue
0.298	0.378	0	3.734455	0.00043

Example: Manual Verification

est <- c(0.345, 0.303, 0.298, 0.378)
err <- c(0.056, 0.101, 0.099, 0.034)

m <- length(est)
Qbar <- mean(est)
Vw <- mean(err^2)
Vb <- var(est)
Vt <- Vw + (1 + 1 / m) * Vb

manual <- c(Estimate = Qbar, Vw = Vw, Vb = Vb, Vt = Vt, SE = sqrt(Vt))
pooled <- c(
  Estimate = out$Estimate, Vw = out$Vw, Vb = out$Vb,
  Vt = out$Vt, SE = out$StdErr
)
rbind(manual = manual, mianalyze = pooled)
#>           Estimate        Vw       Vb       Vt         SE
#> manual       0.331 0.0060735 0.001426 0.007856 0.08863408
#> mianalyze    0.331 0.0060735 0.001426 0.007856 0.08863408

Example: Treatment Difference

est <- c(-2.8, -3.2, -2.5, -3.1, -2.9)
err <- c(1.10, 1.15, 1.05, 1.18, 1.12)
mianalyze(est, err)

Variance Information (5 Imputations)

Between	Within	Total	DF
0.075	1.25636	1.34636	895.1532

Missing Data Diagnostics

Relative Increase in Variance	Fraction Missing Information	Relative Efficiency
0.071636	0.068925	0.986402

Parameter Estimates (5 Imputations)

Estimate	Std Error	LCL	UCL	DF
-2.9	1.160328	-5.177279	-0.622721	895.1532

Hypothesis Test

Minimum	Maximum	Theta0	Statistic	PValue
-3.2	-2.5	0	-2.499294	0.012622

Interpretation:

the pooled estimate is the average treatment difference;
the pooled standard error combines model and imputation uncertainty;
confidence intervals incorporate missing-data uncertainty.

Example: Odds Ratio Analysis

Pool results on the log scale, then exponentiate.

log_or <- c(0.18, 0.21, 0.15, 0.19, 0.23)
se_log_or <- c(0.09, 0.10, 0.09, 0.08, 0.11)
res <- mianalyze(log_or, se_log_or)
res

Variance Information (5 Imputations)

Between	Within	Total	DF
0.00092	0.00894	0.010044	331.0818

Missing Data Diagnostics

Relative Increase in Variance	Fraction Missing Information	Relative Efficiency
0.12349	0.115245	0.97747

Parameter Estimates (5 Imputations)

Estimate	Std Error	LCL	UCL	DF
0.192	0.10022	-0.005148	0.389148	331.0818

Hypothesis Test

Minimum	Maximum	Theta0	Statistic	PValue
0.15	0.23	0	1.91579	0.056253


exp(c(OR = res$Estimate, LCL = res$lcl, UCL = res$ucl))
#>        OR       LCL       UCL
#> 1.2116705 0.9948654 1.4757226

Example: Hazard Ratio Analysis

Cox models typically return log-hazard ratios.

log_hr <- c(-0.22, -0.17, -0.31, -0.28, -0.24)
se <- c(0.14, 0.13, 0.15, 0.12, 0.13)
res <- mianalyze(log_hr, se)
res

Variance Information (5 Imputations)

Between	Within	Total	DF
0.00293	0.01806	0.021576	150.6275

Missing Data Diagnostics

Relative Increase in Variance	Fraction Missing Information	Relative Efficiency
0.194684	0.173856	0.966397

Parameter Estimates (5 Imputations)

Estimate	Std Error	LCL	UCL	DF
-0.244	0.146888	-0.534226	0.046226	150.6275

Hypothesis Test

Minimum	Maximum	Theta0	Statistic	PValue
-0.31	-0.17	0	-1.661133	0.098767


exp(c(HR = res$Estimate, LCL = res$lcl, UCL = res$ucl))
#>        HR       LCL       UCL
#> 0.7834876 0.5861225 1.0473115

Example: Small-Sample Degrees of Freedom

Assume the complete-data analysis would have \(v_0 = 40\):

est <- c(0.345, 0.303, 0.298, 0.378)
err <- c(0.056, 0.101, 0.099, 0.034)

br <- mianalyze(est, err, edf = 40)
rubin <- mianalyze(est, err)

data.frame(
  method = c("Barnard-Rubin (edf=40)", "Rubin large-sample"),
  df = c(br$df, rubin$df),
  lcl = c(br$lcl, rubin$lcl),
  ucl = c(br$ucl, rubin$ucl)
)
#>                   method       df       lcl       ucl
#> 1 Barnard-Rubin (edf=40) 19.57893 0.1458573 0.5161427
#> 2     Rubin large-sample 58.27270 0.1535973 0.5084027

The adjusted degrees of freedom are smaller, producing slightly wider confidence intervals.

Comparison with SAS PROC MIANALYZE

mianalyze() is a univariate analogue of SAS PROC MIANALYZE. The formulas for \(\bar{Q}\), \(\bar{U}\), \(B\), \(T\), \(r\), \(\hat\lambda\), \(RE\), \(v_m\), and the Barnard-Rubin \(v_m^*\) match those in the SAS/STAT User’s Guide (Chapter The MIANALYZE Procedure).

Option mapping

SAS `PROC MIANALYZE`	`mianalyze()`
Estimates + standard errors (e.g. `STDERR` / `PARMS`)	`est`, `err`
`ALPHA=`	`alpha` (default `0.05`)
`THETA0=`	`theta0` (default `0`)
`EDF=` (Barnard-Rubin)	`edf` (default `Inf` = no adjustment)
—	`v0` (deprecated alias for `edf`)

Note: SAS documents a default of EDF=1 with no adjustment when EDF= is omitted. In kstools, omitting edf (or using edf = Inf) likewise uses Rubin’s large-sample \(v_m\) without Barnard-Rubin adjustment.

Scope

Aligned with SAS univariate MI inference:

pooled estimate, total variance, \(t\)-based CI and test;
variance diagnostics \(r\), \(\hat\lambda\), \(RE\);
Barnard-Rubin df via edf.

Not implemented (multivariate SAS features):

Wald multivariate tests (MULT / MULTIVARIATE);
TEST linear hypotheses;
pooling from full covariance matrices alone (without per-parameter SEs).

SAS Example 58.1 (means and standard errors, `EDF=30`)

The Fitness example in SAS/STAT 12.3 Example 58.1 combines univariate means and standard errors across \(m = 5\) imputations with EDF=30 (sample size \(n = 31\)). Reproducing Oxygen from the published input table:

oxygen <- mianalyze(
  est = c(47.0120, 47.2407, 47.4995, 47.1485, 47.0042),
  err = c(0.95984, 0.93540, 1.00766, 0.95439, 0.96528),
  edf = 30
)
oxygen

Variance Information (5 Imputations)

Between	Within	Total	DF
0.04147	0.930854	0.980619	26.29868

Missing Data Diagnostics

Relative Increase in Variance	Fraction Missing Information	Relative Efficiency
0.053461	0.051968	0.989713

Parameter Estimates (5 Imputations)

Estimate	Std Error	LCL	UCL	DF
47.18098	0.990262	45.14659	49.21537	26.29868

Hypothesis Test

Minimum	Maximum	Theta0	Statistic	PValue
47.0042	47.4995	0	47.64495	0

Comparison with SAS Output 58.1.2 / 58.1.3 (Oxygen). Small differences are expected because the User’s Guide prints input means/SEs with limited precision.

sas_oxygen <- data.frame(
  quantity = c(
    "Estimate", "StdErr", "Between", "Within", "Total",
    "DF", "r", "lambda", "RE", "LCL", "UCL"
  ),
  sas = c(
    47.180993, 0.990266, 0.041478, 0.930853, 0.980626,
    26.298, 0.053471, 0.051977, 0.989712, 45.1466, 49.2154
  ),
  mianalyze = c(
    oxygen$Estimate, oxygen$StdErr, oxygen$Vb, oxygen$Vw, oxygen$Vt,
    oxygen$df, oxygen$r, oxygen$lambda, oxygen$re, oxygen$lcl, oxygen$ucl
  )
)
sas_oxygen$abs_diff <- abs(sas_oxygen$mianalyze - sas_oxygen$sas)
knitr::kable(sas_oxygen, digits = 6)

quantity	sas	mianalyze	abs_diff
Estimate	47.180993	47.180980	0.000013
StdErr	0.990266	0.990262	0.000004
Between	0.041478	0.041470	0.000008
Within	0.930853	0.930854	0.000001
Total	0.980626	0.980619	0.000007
DF	26.298000	26.298679	0.000679
r	0.053471	0.053461	0.000010
lambda	0.051977	0.051968	0.000009
RE	0.989712	0.989713	0.000001
LCL	45.146600	45.146592	0.000008
UCL	49.215400	49.215368	0.000032

The same pattern holds for RunTime and RunPulse in that example, and for the Getting Started / Example 58.3 regression coefficients when moments are reconstructed from the published Between/Within variances (with and without EDF=28). Automated checks live in tests/testthat/test-ks_mianalyze-sas.R.

Relative efficiency (SAS Table 58.2)

SAS tabulates \(RE = 1/(1+\lambda/m)\). For illustration:

re_grid <- expand.grid(
  m = c(3, 5, 10, 20),
  lambda = c(0.1, 0.2, 0.3, 0.5, 0.7)
)
re_grid$RE <- with(re_grid, 1 / (1 + lambda / m))
knitr::kable(
  xtabs(RE ~ m + lambda, data = re_grid),
  digits = 4,
  caption = "Relative efficiency (matches SAS Table 58.2)"
)

Relative efficiency (matches SAS Table 58.2)
	0.1	0.2	0.3	0.5	0.7
3	0.9677	0.9375	0.9091	0.8571	0.8108
5	0.9804	0.9615	0.9434	0.9091	0.8772
10	0.9901	0.9804	0.9709	0.9524	0.9346
20	0.9950	0.9901	0.9852	0.9756	0.9662

API correspondence

SAS:

proc mianalyze data=outuni edf=30;
  modeleffects Oxygen;
  stderr SOxygen;
run;

Equivalent R:

mianalyze(est = oxygen_est, err = oxygen_se, edf = 30)

Typical Clinical Trial Workflow

A common workflow with the mice package:

library(mice)

imp <- mice(adsl, m = 20)

fits <- with(
  imp,
  lm(CHG ~ TRT01A + BASE)
)

est <- sapply(
  fits$analyses,
  function(x) coef(summary(x))["TRT01AActive", "Estimate"]
)

err <- sapply(
  fits$analyses,
  function(x) coef(summary(x))["TRT01AActive", "Std. Error"]
)

mianalyze(est, err)

Interpreting Output

Variance Components

Component	Meaning
\(V_w\) (`Vw`)	Within-imputation variance \(\bar{U}\)
\(V_b\) (`Vb`)	Between-imputation variance \(B\)
\(V_t\) (`Vt`)	Total variance \(T\)

Large \(V_b\) relative to \(V_w\) indicates substantial missing-data uncertainty.

Missing Information

Metric	Meaning
\(r\)	Relative increase in variance
\(\lambda\)	Fraction of missing information
\(RE\)	Relative efficiency

Inference

Statistic	Meaning
Estimate	Pooled estimate \(\bar{Q}\)
StdErr	Pooled standard error \(\sqrt{T}\)
lcl / ucl	Confidence interval
\(t\)	Test statistic for \(H_0{:}\,\theta=\theta_0\)
pval	Two-sided \(p\)-value

Special Cases

Single Imputation

mianalyze(est = 10, err = 2)

Variance Information (1 Imputations)

Between	Within	Total	DF
0	4	4	Inf

Missing Data Diagnostics

Relative Increase in Variance	Fraction Missing Information	Relative Efficiency
0	0	1

Parameter Estimates (1 Imputations)

Estimate	Std Error	LCL	UCL	DF
10	2	6.080072	13.91993	Inf

Hypothesis Test

Minimum	Maximum	Theta0	Statistic	PValue
10	10	0	5	1e-06

Here \(B = 0\), \(T = \bar{U}\), and results reduce to ordinary complete-data inference.

No Between-Imputation Variability

mianalyze(est = rep(5, 5), err = rep(1, 5))

Variance Information (5 Imputations)

Between	Within	Total	DF
0	1	1	Inf

Missing Data Diagnostics

Relative Increase in Variance	Fraction Missing Information	Relative Efficiency
0	0	1

Parameter Estimates (5 Imputations)

Estimate	Std Error	LCL	UCL	DF
5	1	3.040036	6.959964	Inf

Hypothesis Test

Minimum	Maximum	Theta0	Statistic	PValue
5	5	0	5	1e-06

When all imputations produce the same estimate, \(B = 0\) and no additional uncertainty is attributed to missing data.

Summary

mianalyze() / ks_mianalyze() pool MI point estimates and standard errors with Rubin’s rules: \(\bar{Q}\), \(T = \bar{U}+(1+1/m)B\), \(t\)-based intervals and tests.
Diagnostics \(r\), \(\hat\lambda\), and \(RE\) quantify the impact of missingness and the efficiency of finite \(m\).
edf applies the Barnard-Rubin (1999) small-sample df adjustment, matching SAS EDF=.
Agreement with SAS univariate PROC MIANALYZE was checked against SAS/STAT 12.3 formulas, Table 58.2, Example 58.1 (EDF=30), and Example 58.3 (EDF=28).
Pool on the analysis scale (e.g. log-OR, log-HR), then transform intervals if needed.
Prefer edf whenever complete-data residual df are modest so that \(v_m\) does not exceed the information in the original sample.

References

Barnard, J. and Rubin, D.B. (1999). Small-sample degrees of freedom with multiple imputation. Biometrika, 86, 948–955.

Rubin, D.B. (1987). Multiple Imputation for Nonresponse in Surveys. Wiley.

SAS Institute Inc. (2013). SAS/STAT 12.3 User’s Guide. Chapter 58, The MIANALYZE Procedure. Cary, NC: SAS Institute Inc.

Van Buuren, S. (2018). Flexible Imputation of Missing Data. Second Edition. Chapman & Hall/CRC.

This post was originally published on the KeyStat Solutions R Technical Blog. Visit R-Bloggers to discover more R content.

Introduction

Multiple Imputation Workflow

Rubin’s Rules

Pooled Estimate

Within-Imputation Variance

Between-Imputation Variance

Total Variance

Relative Increase in Variance

Fraction of Missing Information

Relative Efficiency

Degrees of Freedom

Rubin (1987)

Problem with Large-Sample Degrees of Freedom

Barnard-Rubin Adjustment

Basic Example

Variance Information (4 Imputations)

Missing Data Diagnostics

Parameter Estimates (4 Imputations)

Hypothesis Test

Example: Manual Verification

Example: Treatment Difference

Variance Information (5 Imputations)

Missing Data Diagnostics

Parameter Estimates (5 Imputations)

Hypothesis Test

Example: Odds Ratio Analysis

Variance Information (5 Imputations)

Missing Data Diagnostics

Parameter Estimates (5 Imputations)

Hypothesis Test

Example: Hazard Ratio Analysis

Variance Information (5 Imputations)

Missing Data Diagnostics

Parameter Estimates (5 Imputations)

Hypothesis Test

Example: Small-Sample Degrees of Freedom

Comparison with SAS PROC MIANALYZE

Option mapping

Scope

SAS Example 58.1 (means and standard errors, EDF=30)

Variance Information (5 Imputations)

Missing Data Diagnostics

Parameter Estimates (5 Imputations)

Hypothesis Test

Relative efficiency (SAS Table 58.2)

API correspondence

Typical Clinical Trial Workflow

Interpreting Output

Variance Components

Missing Information

Inference

Special Cases

Single Imputation

Variance Information (1 Imputations)

Missing Data Diagnostics

Parameter Estimates (1 Imputations)

Hypothesis Test

No Between-Imputation Variability

Variance Information (5 Imputations)

Missing Data Diagnostics

Parameter Estimates (5 Imputations)

Hypothesis Test

Summary

References

SAS Example 58.1 (means and standard errors, `EDF=30`)
